Hybrid locomotion system
Moves quickly on wheels over flat surfaces; automatically switches to leg mode over obstacles or uneven terrain to maintain mobility.
QUADRUPED ROBOTS · GALILEO
GALILEO C1-W
Hybrid mobile inspection robot that transitions from wheels to legs.
GALILEO C1-W is a hybrid mobile platform that accelerates on wheels over flat surfaces and switches to leg mode when encountering an obstacle. IP67 joints and a wide operating temperature range allow it to perform missions outside indoor facilities as well.
- Speed
- 0-5 m/s · Wheeled leg
- Transport
- 12 kg · Continuous payload
- Operating time
- 3-5 hours · Per charge
1 / 4
SELECT BY TASK
GALILEO C1-W
what is it evaluated for?
GALILEO C1-W is the wheeled-legged version of the C1 body: it moves efficiently on wheels over flat surfaces and switches to leg mode to continue over obstacles or uneven terrain. The 22 kg body is light enough for one person to carry and can carry a 12 kg payload during continuous walking. Its joints are IP67-protected and it has an operating temperature range of -20°C to 55°C, making it suitable for inspection tasks outside indoor facilities. Autonomous charging support and an extended low-power standby mode allow it to wait at its station between missions and then resume work. Its design is open to secondary development, allowing additional sensors and software layers to be integrated.
PRODUCT-SPECIFIC
Key features.
Features compiled from source product information; evaluate according to the model and configuration.
Lightweight, portable body
The 22 kg body is designed to be carried by one person, making it easier to use in field operations.
Payload during continuous walking
The system can be configured to carry a 12 kg payload during continuous walking, supporting sensors and small computing modules.
IP67-protected joints
The joints are protected against dust and water ingress, providing durability suitable for outdoor conditions.
Wide operating temperature range
An operating capability from -20°C to 55°C enables the device to operate in environments outside indoor facilities.
Autonomous charging and standby mode
The robot can return to its charging station after a mission; extended low-power standby allows it to remain ready between missions.
Structure open to secondary development
An open design that allows additional sensors and software layers to be integrated for specialized applications such as water management, energy, security, or rail systems.
SOURCED PRODUCT DATA
Technical features.
Values are taken from the source product page. Confirm the package, software, and accessory contents against the manufacturer's current documentation before ordering.
| Feature | Value |
|---|---|
| Dimensions (standing) | 765 x 480 x 540 mm (length x width x height) |
| Weight | 28,5 kg |
| Payload while walking | 12 (during continuous walking) |
| Maximum speed | 0-5 m/s (adjustable) |
| Climbing angle | ≥30° |
| Obstacle and step | ≥20 cm continuous step |
| Battery capacity | 960 Wh |
| Battery | 48 V 20 Ah (960 Wh); supports autonomous charging |
| Battery voltage | 48 V |
| Operating time | 3-5 hours |
| Processor | ARM-based low-power processor (8 cores 8 threads, 8 GB RAM, 64 GB SSD) |
| Software features | Supports secondary development; dual-band Wi-Fi 6; low-power mode with remote wake-up (≥365 days) |
| Protection rating | IP67 (joint) |
| Operating temperature | -20°C to 55°C |
SEE THE PRODUCT IN ACTION
GALILEO C1-W introduction.
The introduction video linked from the source product page opens when you press the play button.
PRODUCT INFORMATION SOURCES
Sources and documentation.
This catalog is intended to help explore product information. No commitments are made on behalf of Robotik Çözümler regarding stock, authorized dealers, pricing, warranty, or after-sales service terms.
FREQUENTLY ASKED QUESTIONS
Frequently asked questions.
How much payload can C1 carry?
Carries a 12 kg payload during continuous walking; this capacity is sufficient to support sensor towers and small computing modules.
Can it operate outdoors?
The joints are IP67-protected and the body can operate between -20°C and 55°C; it is suitable for outdoor inspections in rain and dust.
Can I run my own software?
Secondary development is supported; external interfaces and computing units can be integrated onto the body.
