EngineAI T800

173 cm tall, high-dynamic general-purpose humanoid robot.

EngineAI T800 is a full-size, general-purpose humanoid robot. It offers various hardware configurations and up to five hours of field operation.

Height: 173 cm · 75-85 kg
Torque: 450 Nm · Peak joint torque
Degrees of freedom: 25-46 · Depending on version

Request a quote / demo

1 / 4

SELECT BY TASK

EngineAI T800
what is it evaluated for?

EngineAI T800 is a full-size, general-purpose humanoid robot designed with in-house actuator and leg technologies. Standing 173 cm tall and weighing 75–85 kg depending on the version, T800 combines high torque output, hardware-assisted high-speed capability, and active cooling in the leg joints for extended operation. Its multiple configurations—Basic, Open Source, Pro, and Max—offer different DoF, sensing, and manipulation capabilities. With its modular chassis, advanced perception packages, and optional energy-dense battery options, it adapts to a wide range of applications.

Logistics warehouse collaboration

PRODUCT-SPECIFIC

Key features.

Features compiled from source product information; evaluate according to the model and configuration.

High dynamic power

T800's joint architecture is designed to deliver high peak torque, making it suitable for fast, powerful movements and high-dynamic tasks.

Modular configurations

The Basic, Open Source, Pro, and Max versions offer different degrees of freedom and sensing/computing packages to meet research, demonstration, and advanced manipulation needs.

Extended operation and fast-charging options

Standard and optional battery configurations allow field operating time and charging time to be adjusted to requirements; the quick-swap battery design supports setups suited to shift-based use.

Sustained operation with active cooling

Active cooling in the leg joints reduces performance degradation during high-intensity tasks, supporting longer periods of uninterrupted operation.

Dexterous manipulation (Pro/Max)

The multi-degree-of-freedom hands on the Pro and Max versions are suited to precision manipulation tasks, with integrated tactile sensing and object-grasping capability.

Durable, modular exterior design

The body, clad in aerospace-grade aluminum panels, provides a suitable platform for modular accessories and protective components.

Standard communications and access hardware

Connectivity and interaction components such as Wi‑Fi, Bluetooth, USB, LAN, a microphone, and a speaker are included as standard.

SOURCED PRODUCT DATA

Technical features.

Values are taken from the source product page. Confirm the package, software, and accessory contents against the manufacturer's current documentation before ordering.

EngineAI T800 technical specifications
Feature	Value
Dimensions (standing)	173 cm tall; calf + thigh 91 cm, arm 60 cm
Weight	75-85 kg (depending on version)
Arm reach	60 cm (single arm length)
Arm payload	5 kg per dexterous hand (Pro and Max), 7 DoF, tactile sensing
Maximum speed	3 m/s and above (with hardware support)
Joint torque	450 Nm
Joint motion range — source field	Waist: Y -251° to 71°; Hip: R -118° to 62°, P -190° to 130°, Y -81° to 206°; Knee: P -15° to 135°; Foot: P -39° to 39°, R -15° to 15°; Head: P -30° to 30°, Y -70° to 70°; Shoulder: P -170° to 160°, R -140° to 22°, Y -150° to 150°; Elbow: P -131° to 15°, R -150° to 150°; Wrist: P -25° to 25°, R -35° to 65° (may vary by version)
Battery	Standard ternary lithium battery: 71,4 V fully charged, 20 Ah, 2,5-hour charge; optional solid-state battery: 74,8 V, 40 Ah, 3-hour charge; quick-removable smart battery
Operating time	4-5 hours per charge
Charging time	Ternary lithium battery: 2,5 hours; solid-state battery: 3 hours
Modes of movement	Full-size bipedal humanoid; 25 DoF (Basic, Open Source), 43 DoF (Pro), 46 DoF (Max)
Degrees of freedom	25 (Basic and Open Source) / 43 (Pro: 29 + 14 dexterous hand) / 46 (Max: 32 + 14 dexterous hand)
Arm degrees of freedom	5 (Basic, Open Source, Pro) / 7 (Max)
Leg degrees of freedom	6 DoF
Waist degrees of freedom	1 (Basic, Open Source, Pro) / 3 (Max)
Neck degrees of freedom	2 DoF
End effector	Pro and Max: 7 degrees of freedom per dexterous hand. Basic and Open Source versions have no hands (0 DoF per hand).
Joint motor	Planetary gear joint; planetary + linear force-controlled joints on Pro and Max. Absolute dual encoders.
Torque density	Peak joint torque 450 Nm; planetary gear joints, linear force-controlled joints on Pro and Max; absolute dual encoders
Material	Aerospace-grade aluminum alloy panels, streamlined high-strength chassis; 75-85 kg body
Cooling	Active cooling in leg joints; peak performance under heavy loads and high temperatures
Manufacturer's note	Joint ranges of motion (may vary by version): waist Y -251 to 71, hip R -118 to 62, P -190 to 130, Y -81 to 206, knee P -15 to 135, foot P -39 to 39 and R -15 to 15, head P -30 to 30 and Y -70 to 70, shoulder P -170 to 160, R -140 to 22, Y -150 to 150, elbow P -131 to 15 and R -150 to 150, wrist P -25 to 25 and R -35 to 65 degrees. Neck DoF 2 (3 on Max).
Degrees of freedom by version	Basic and Open Source 25; Pro 29 + 14 hands = 43; Max 32 + 14 hands = 46
Joint configuration	Neck 2 (Max 3), waist 1 (Max 3), 5 per arm (Max 7), 6 per leg, 7 per hand (Pro and Max)
Joint motion range — source field (2)	Waist Y -251° to 71°; hip R -118° to 62°, P -190° to 130°, Y -81° to 206°; knee P -15° to 135°; foot P ±39°, R ±15°; head P ±30°, Y ±70°; shoulder P -170° to 160°, R -140° to 22°, Y ±150°; elbow P -131° to 15°, R ±150°; wrist P ±25°, R -35° to 65°
Actuator	Planetary gear joints, absolute dual encoders, 450 Nm peak torque; additional linear force control on Pro and Max; fully articulated internal cabling
Battery module	Optional modular solid-state lithium battery architecture for increased energy density and powerful operation for up to 4 hours
Sensors	Basic: Intel depth camera; Open Source, Pro, Max: stereo vision + 360-degree LiDAR, open visual hardware interface compatible with Intel and other cameras; millisecond-level environmental data processing
Connectivity	Wi-Fi + Bluetooth + USB + LAN
Wireless	Wi-Fi, Bluetooth, USB, LAN
Interaction	Microphone, speaker, 2 head lights + 2 chest lights + knee lights, hand controller
Joint encoder	Absolute dual encoders
Processor	Robot computer: Intel module (optional RK3588); AI computer: NVIDIA Jetson Orin NX 16 GB (Basic) or AGX Orin 64 GB (Open Source, Pro, Max; upgradeable)
Software features	Seamless transitions between complex movements; martial arts, dexterous manipulation and grasping; secondary development (Open Source, Pro, Max)
Expansion module	High-performance computing module (AI PC): Orin NX 16 GB in the Basic version; AGX Orin 64 GB in the Open Source, Pro and Max versions (processing power upgradeable). Base processing power (Robot PC) is listed separately.

SEE THE PRODUCT IN ACTION

EngineAI T800 introduction.

The introduction video linked from the source product page opens when you press the play button.

PRODUCT INFORMATION SOURCES

Sources and documentation.

This catalog is intended to help explore product information. No commitments are made on behalf of Robotik Çözümler regarding stock, authorized dealers, pricing, warranty, or after-sales service terms.

FREQUENTLY ASKED QUESTIONS

Frequently asked questions.

What technical configurations are available for T800?

T800 is available in Basic, Open Source, Pro and Max versions. These versions feature different degrees of freedom, computing units and perception packages; Pro and Max come with more advanced hands and additional control capabilities.

How are power and operating times managed?

The device offers standard and optional battery configurations; its design supports fast charging and modular battery replacement, enabling continuous operation.

What capabilities do the hands in the Pro and Max versions provide?

The hands in the Pro and Max versions each offer multiple degrees of freedom and integrated tactile sensing, enabling delicate grasping and flexible manipulation tasks.
